Home > Alloy Steel > 15Mo3 Pipes
Rithav Pipes and Tubes is a well-respected manufacturer and supplier of top-notch 15Mo3 Pipes based in Delhi, India. We take pride in providing high-quality 15Mo3 alloy steel pipes that are specifically designed for demanding high-temperature and high-pressure applications. Our pipes are crafted in accordance with international standards like DIN 17175 and EN 10028-2, making them a trusted choice for industries around the globe, thanks to their outstanding performance and reliability. As one of the leading suppliers in India, Rithav Pipes and Tubes guarantees prompt delivery, competitive pricing, and unparalleled quality for all your needs related to boilers, pressure vessels, and heat exchangers.
15Mo3 Pipes are made from alloy steel that includes molybdenum (0.25-0.35%) and manganese (0.40-0.90%) as essential components. The chemical makeup also features carbon (0.12-0.20%), silicon (0.20-0.35%), along with small amounts of phosphorus and sulfur. In terms of mechanical properties, 15Mo3 boasts a tensile strength ranging from 440-590 MPa, a minimum yield strength of 290 MPa, and an elongation of at least 22%. These characteristics make 15Mo3 perfect for high-temperature applications, as it shows excellent creep resistance and good weldability. The material’s strength at elevated temperatures ensures it performs reliably in challenging thermal conditions.
| Welded Pipe Size | 5.0 mm – 1219.2 mm |
|---|---|
| Grade 15Mo3 DIN 2609 EFW Pipe size | 5.0 mm – 1219.2 mm |
| CS Tube Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Standard | AISI, DIN, EN, GB, IS, JIS, ASTM, ASME Pipe |
| Mild Steel Seamless Pipe Size | 4 to 219mm W. T.: 0.5 to 20mm |
| Carbon Steel DIN 2609 Grade 15Mo3 Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| DIN 2609 Gr 15Mo3 Pipe Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| CS Welded Tube Size | 6.35 mm OD To 152 mm OD |
| DIN 2609 Gr. 15Mo3 Tube wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| DIN 2609 Gr St52 Carbon Steel Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| High Temperature Carbon Steel DIN 2609 Gr 15Mo3 Form | Round, Hydraulic, ‘U’ bent or Hollow,LSAW, Boiler, Straight Pipe, Clad Pipe, Rectangular, Square Pipe Etc |
| DIN Gr. 2609 15Mo3 Steel Length | Single Random, Double Random, Standard & Cut length Pipe & Tube |
| Mild Steel Marking | All Tubes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Low Temperature Carbon Steel DIN 2609 Grade 15Mo3 Application | Oil Pipe & Tube, Gas Pipe & Tube, Fluid Pipe & Tube, Boiler Pipe & Tube, Heat exchanger Tube |
| Type | Welded, Seamless, ERW, EFW, Fabricated Pipe, ‘U’ bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Tube etc |
| DIN Gr. 15Mo3 Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Grade 15Mo3 DIN 2609 Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| 2609 Gr. 15Mo3 End | Plain End, Beveled End, Treaded Pipe & Tube |
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
|---|---|---|---|---|---|---|---|---|---|
| 0.12 – 0.20 | 0.10 – 0.35 | 0.40 – 0.80 | 0.035 | 0.035 | 0.25 – 0.35 | – | – | – | – |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 450 | 600 | – | 22 | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing 15Mo3 pipes from Rithav Pipes and Tubes ensures you receive high-quality products tailored for demanding applications. Our pipes are manufactured using premium-grade alloy steel, guaranteeing exceptional strength, durability, and resistance to high temperatures. We adhere to strict quality control measures, ensuring that each pipe meets industry standards and specifications. With our commitment to customer satisfaction, we offer competitive pricing, timely delivery, and expert technical support. Trust Rithav Pipes and Tubes for reliable, high-performance solutions for your industrial needs.
Rithav Pipes and Tubes, one of the largest suppliers of 15Mo3 Pipes in Delhi, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
Yes, we offer custom sizes for 15Mo3 Pipes to meet your specific requirements. Our team at Rithav Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@rithavpipesandtubes.co.in.
| Equivalent Designation | |||||
| DIN | EN | BS | NFA | ASTM | ASME |
|---|---|---|---|---|---|
| DIN 2609 Grade 15Mo3 | – | – | – | – | – |
15Mo3 Pipes find extensive use in sectors such as power generation, petrochemical, and oil & gas, thanks to their ability to endure high temperatures and pressures. They are commonly used in the production of boilers, pressure vessels, heat exchangers, and steam pipelines. The alloy’s remarkable resistance to oxidation and heat scaling makes it particularly suitable for thermal power plants and refineries. Furthermore, 15Mo3 is also ideal for applications in chemical plants, fertilizer industries, and offshore structures. Rithav Pipes and Tubes provides 15Mo3 pipes that adhere to stringent safety and quality standards, making them the go-to choice for high-temperature service installations.
