Carbon Steel A671 GR CC 70 Pipes

Home > Carbon Steel > Carbon Steel A671 GR CC 70 Pipes

Carbon Steel A671 GR CC 70 Pipes Manufacturer, Supplier and Exporter in Delhi, India

Rithav Pipes and Tubes, located in Delhi, India, has earned a solid reputation as a reliable manufacturer and supplier of top-quality Carbon Steel A672 GR CC 70 Pipes. These pipes are celebrated for their impressive strength, durability, and performance, especially in high-pressure situations. Crafted through electric fusion welding (EFW), they are perfect for moderate to high-temperature applications. With cutting-edge production techniques and strict adherence to ASTM standards, Rithav guarantees consistent quality, precise dimensions, and dependable performance. Our A672 GR CC 70 pipes cater to essential industries like oil & gas, power generation, petrochemicals, and infrastructure, fulfilling a wide range of industrial needs both in India and globally.

Carbon Steel A671 GR CC70 Pipes Supplier in Delhi, Carbon Steel A671 GR CC70 Pipes Exporter in India, ASTM A671 GR CC70 Pipes Sizes in mm, Carbon Steel A671 GR CC70 Pipes Manufacturer in Delhi, Carbon Steel A671 GR CC70 Pipe Price List in Delhi, ASTM A671 GR CC70 Pipes Distributor in Delhi, Carbon Steel A671 GR CC70 Pipes in India, Carbon Steel A671 GR CC70 Pipes Supplier in Delhi, Carbon Steel A671 GR CC70 Pipes Distributor in India

Carbon Steel A672 GR CC 70 Pipes are made from carbon steel plates of Grade C70 and are produced using electric fusion welding. The typical chemical makeup features carbon (max 0.30%), manganese (0.60–0.90%), phosphorus (max 0.035%), sulfur (max 0.040%), and trace amounts of silicon. These pipes boast remarkable mechanical strength, with a minimum tensile strength of around 485 MPa and a yield strength of 260 MPa, ensuring good toughness and the ability to handle pressure. They are heat-treatable and designed for moderate to high-temperature services, offering excellent weldability, structural integrity, and long-lasting durability.

Carbon Steel A671 GR CC70 Pipes Specification

Specification	ASTM A671 /ASME SA671
Material Test Certificate	Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS ETC
Type	EFW (ELECTRIC FUSION WELDED PIPES)
Material	A515 Gr 70
Outer Diameter Size	16″ NB To 100″ NB (Nominal Bore Size)
Wall Thickness	Schedule 20 To Schedule XXS (Heavier On Request) Up to 250 mm Thickness
Packaging	Loose / Bundle / Wooden Pallet / Wooden Box / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector
Class Designation	CLASS 10, 11, 12, 13, 20, 21, 22, 23, 30, 31, 32, 33, 40, 41, 42
Length	5 To 7 Meters, 09 To 13 Meters, Single Random Length, Double Random Length And Customize Size.
Other Testing	NACE MR0175, NACE TM0177, NACE TM0284, CHARPY V-NOTCH TEST, RADIOGRAPHIC EXAMINATION, XRAY, ULTRASONIC EXAMINATION, LIQUID PENETRANT, MAGNETIC PARTICLE, HIC TEST, SSC TEST, SWC, H2 SERVICE, IBR, PWHT etc.
Dimension	All Pipes Is Manufactured and Inspected / Tested to the Relevant standards including ASTM, ASME, API.
Value Added Services	Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Galavanizing / Heat Treatment
Coating	Epoxy Coating / Colour Paint Coating / 3LPE Coating.
Shipment & Transportation	By Road – Truck / Train, By Sea – Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet Container / 45 Feet Container / High Cube Container / Open Top Container, By Air – Freighter Civil Passenger and Cargo Planes
Standards	CC70, JIS JPI-SB49

Carbon Steel A671 GR CC70 Pipes Chemical Composition

A672 Grades	Chemical composition
A672 Grades	C	Si	Mn	P	S	Ti
CC70 / C70	0.27		~1.30

Carbon Steel A671 GR CC70 Pipes Mechanical Properties

A672 Grades	Yield Strength (N/mm2)	Tensile Properties (N/mm2)	Elongation (%)	Welding point tensile strength (N/mm2)
CC70 / C70	260	485~620	21	485~620

If You Are Looking To Buy High Quality

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

ASTM A671 GR CC70 Pipe Exporter in India, Carbon Steel A671 GR CC70 Pipes Price List in Delhi, Carbon Steel A671 GR CC70 Pipes Supplier in India, Carbon Steel A671 GR CC70 Pipes Exporter in Delhi, Carbon Steel A671 GR CC70 Pipes Exporter in Delhi, ASTM A671 GR CC70 Pipes Size Chart, Carbon Steel A671 GR CC70 Pipes Price in India, Carbon Steel A671 GR CC70 Pipe Weight Chart, ASTM A671 GR CC70 Pipes Thickness, Carbon Steel A671 GR CC70 Pipes Supplier in Delhi, Carbon Steel A671 GR CC70 Pipe Stockist in India

Why Choose Carbon Steel A671 GR CC70 Pipes from Rithav Pipes and Tubes?

Choosing Carbon Steel A671 GR CC70 Pipes from Rithav Pipes and Tubes ensures outstanding corrosion resistance, high strength, and durability. Our Pipe is designed for diverse industrial applications, delivering reliability and performance in challenging environments while maintaining competitive pricing.

Customer Support

On Time Deliveries

Largest Inventory

Worldwide Shipping

Carbon Steel A671 GR CC70 Pipes Size Chart

NB	Size	OD	40S	5S	10S	S10	S20	S40	S60	XS/80S	S80	S100	S120	S140	S160	XXS
NB	Size	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm
	1/8”	10.29			1.2			1.73			2.41
	1/4”	13.72			1.7			2.24			3.02
	3/8”	17.15			1.7			2.31			3.2
15	1/2”	21.34	2.8	1.7	2.1			2.77		3.73	3.73				4.78	7.47
20	3/4”	26.67	2.9	1.7	2.1			2.87		3.91	3.91				5.56	7.82
25	1”	33.4	3.4	1.7	2.8			3.38		4.55	4.55				6.35	9.09
32	1 1/4”	42.16	3.6	1.7	2.8			3.56		4.85	4.85				6.35	9.7
40	1 1/2”	48.26	3.7	1.7	2.8			3.68		5.08	5.08				7.14	10.2
50	2”	60.33	3.9	1.7	2.8			3.91		5.54	5.54				9.74	11.1
65	2 1/2”	73.03	5.2	2.1	3.1			5.16		7.01	7.01				9.53	14
80	3”	88.9	5.5	2.1	3.1			5.49		7.62	7.62				11.1	15.2
90	3 1/2”	101.6	5.7	2.1	3.1			5.74		8.08	8.08
100	4”	114.3	6	2.1	3.1			6.02		8.56	8.56		11.1		13.5	17.1
125	5”	141.3	6.6	2.8	3.4			6.55		9.53	9.53		12.7		15.9	19.1
150	6”	168.3	7.1	2.8	3.4			7.11		10.97	11		14.3		18.3	22
200	8”	219.1	8.2	2.8	3.8		6.4	8.18	10.3	12.7	12.7	15.1	19.3	20.6	23	22.2
250	10”	273.1	9.3	3.4	4.2		6.4	9.27	12.7	12.7	15.1	19.3	21.4	25.4	28.6	25.4
300	12”	323.9	9.5	4	4.6		6.4	10.3	14.3	12.7	17.5	21.4	25.4	28.6	33.3	25.4
350	14”	355.6	9.5	4	4.8	6.4	7.9	11.1	15.1	12.7	19.1	23.8	27.8	31.8	35.7
400	16”	406.4	9.5	4.2	4.8	6.4	7.9	12.7	16.7	12.7	21.4	26.2	31	36.5	40.5
450	18”	457.2	9.5	4.2	4.8	6.4	7.9	14.3	19.1	12.7	23.8	29.4	34.9	39.7	45.2
500	20”	508	9.5	4.8	5.5	6.4	9.5	15.1	20.6	12.7	26.2	32.5	38.1	44.5	50
550	22”	558.8	9.5	4.8	5.5	6.4	9.5		22.2	12.7	28.6	34.9	41.3	47.6	54
600	24”	609.6	9.5	5.5	6.4	6.4	9.5	17.5	24.6	12.7	31	38.9	46	52.4	59.5
650	26”	660.4	9.5			7.9	13			12.7
700	28”	711.2	9.5			7.9	13			12.7
750	30”	762	9.5	6.4	7.9	7.9	13			12.7
800	32”	812.8	9.5			7.9	13	17.5		12.7
850	34”	863.6	9.5			7.9	13	17.5		12.7
900	36”	914.4	9.5			7.9	13	19.1		12.7

Carbon Steel A671 GR CC70 Pipes Material Equivalent

ASTM A671 Grade CC70 Pipe Types	Out diameter	Wall thickness	Length
ASTM A671 Grade CC70 SAW Pipe	16″ NB – 100″ NB	As per requirement	Custom
ASTM A671 Grade CC70 Seamless Pipe (Custom Sizes)	1/2″ NB – 60″ NB	SCH 5 / SCH 10 / SCH 40 / SCH 80 / SCH 160	Custom
ASTM A671 Grade CC70 ERW Pipe (Custom Sizes)	1/2″ NB – 24″ NB	As per requirement	Custom
ASTM A671 Grade CC70 Welded Pipe (in Stock + Custom Sizes)	1/2″ NB – 24″ NB	As per requirement	Custom

Largest Carbon Steel A671 GR CC70 Pipes Supplier in Delhi, India

Rithav Pipes and Tubes is one of the largest Carbon Steel A671 GR CC70 Pipes suppliers in Delhi, India, providing a comprehensive range of high-quality pipes tailored for various industries, ensuring reliable delivery and exceptional service to meet diverse project needs.

Carbon Steel A671 GR CC70 Pipes Exporter in India, Carbon Steel A671 GR CC70 Pipes Price List in Delhi, ASTM A671 GR CC70 Pipes Supplier in India, Carbon Steel A671 GR CC70 Pipes Exporter in Delhi, Carbon Steel A671 GR CC70 Pipes Exporter in Delhi, Carbon Steel A671 GR CC70 Pipes Size Chart, Carbon Steel A671 GR CC70 Pipes Price in India, Carbon Steel A671 GR CC70 Pipes Weight Chart, Carbon Steel A671 GR CC70 Pipes Thickness, ASTM A671 GR CC70 Pipes Supplier in Delhi, Carbon Steel A671 GR CC70 Pipes Stockist in India

Types of Carbon Steel A671 GR CC70 Pipes

Are Custom Sizes Available for Carbon Steel A671 GR CC70 Pipes?

Yes, we offer custom sizes for Carbon Steel A671 GR CC70 Pipes to meet your specific requirements. Our team at Rithav Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@rithavpipesandtubes.co.in.

Carbon Steel A671 GR CC70 Pipes Supplier in Delhi, ASTM A671 GR CC70 Pipes Exporter in India, CS A671 GR CC70 Pipes Manufacturer in Delhi, Carbon Steel A671 GR CC70 Pipes Price List in Delhi, Carbon Steel A671 GR CC70 Pipes Distributor in Delhi, Carbon Steel A671 GR CC70 Pipes in India, ASTM A671 GR CC70 Pipes Supplier in Delhi, Carbon Steel A671 GR CC70 Pipes Distributor in India, Carbon Steel A671 GR CC70 Pipe Sizes in mm

Carbon Steel A672 GR CC 70 Pipes find extensive use in high-pressure and high-temperature settings across various sectors, including oil & gas, thermal power plants, petrochemical refineries, and water treatment facilities. They are particularly well-suited for transporting steam, oil, gas, and other fluids under demanding conditions. Additionally, these pipes are commonly used in boiler systems, condensers, and heat exchangers due to their robust structure and thermal resistance. Their excellent weldability and mechanical properties make them ideal for both underground and above-ground pipelines, ensuring reliability in diverse applications.
