Home > Carbon Steel > Carbon Steel API 5L Grade X42 Pipes
Rithav Pipes and Tubes, a reputable manufacturer and supplier located in Delhi, India, specializes in high-quality Carbon Steel API 5L Grade X42 Pipes. These pipes are designed for dependable performance in oil, gas, and water transportation systems. Built according to the API 5L specification, X42 pipes are perfect for both onshore and offshore pipeline projects that demand strength, durability, and resistance to corrosion. Rithav offers these pipes in both seamless and welded forms, available in PSL1 and PSL2 variants, and can provide custom sizes, coatings, and end finishes to meet global quality standards.
API 5L X42 Pipes are generally made up of carbon (≤0.26%), manganese (up to 1.65%), and trace elements like phosphorus and sulfur (≤0.030%). Optional alloying elements such as niobium, vanadium, and titanium are included in PSL2 grades. These pipes boast a minimum yield strength of 290 MPa and a tensile strength ranging from 415 to 760 MPa, depending on the product specification level. Renowned for their excellent weldability, fracture toughness, and chemical resistance, API 5L X42 pipes are well-suited for demanding environments, including sour service and CO₂-rich conditions, particularly in PSL2 variants.
| Mechanical Properties PSL 1 | |||||
| Grade | Yield Strength(Min.) | Tensile Strength(Min.) | Elongation | ||
| Ksi | MPa | Ksi | MPa | E=1944 A 0.2 /U 0.9 | |
| B | 35 | 241 | 60 | 414 | |
| X42 | 42 | 290 | 60 | 414 | |
| X46 | 46 | 317 | 63 | 434 | |
| X52 | 52 | 359 | 66 | 455 | |
| X56 | 56 | 386 | 60 | 414 | |
| X60 | 60 | 414 | 63 | 434 | |
| X65 | 65 | 448 | 66 | 455 | |
| Chemical Composition % | ||||||||
| PSL1 | PSL2 | |||||||
| Grade | C (Max.) | Mn(Max.) | P(Max.) | S(Max.) | C (Max.) | Mn(Max.) | P(Max.) | S(Max.) |
| A | 0.22 | 0.90 | 0.03 | 0.03 | 0.22 | 1.20 | 0.025 | 0.015 |
| B | 0.26 | 1.20 | 0.03 | 0.03 | 0.22 | 1.30 | 0.025 | 0.015 |
| X42 | 0.26 | 1.30 | 0.03 | 0.03 | 0.22 | 1.40 | 0.025 | 0.015 |
| X46 | 0.26 | 1.40 | 0.03 | 0.03 | 0.22 | 1.40 | 0.025 | 0.015 |
| X52 | 0.26 | 1.40 | 0.03 | 0.03 | 0.22 | 1.40 | 0.025 | 0.015 |
| X56 | 0.26 | 1.40 | 0.03 | 0.03 | 0.22 | 1.40 | 0.025 | 0.015 |
| X60 | 0.26 | 1.40 | 0.03 | 0.03 | 0.22 | 1.45 | 0.025 | 0.015 |
| X65 | 0.26 | 1.45 | 0.03 | 0.03 | 0.22 | 1.65 | 0.025 | 0.015 |
| X70 | 0.26 | 1.65 | 0.03 | 0.03 | 0.22 | 1.85 | 0.025 | 0.015 |
PSL 2 Pipe Sizes: Nominal Pipe Size 1/2″ to 48 ” O.D.
Wall Thickness: Schedule 10 through 160, STD, XS, XXS.
API 5L PSL 2 Seamless Pipe: B (L245) – X42 (L290) – X52N (L360) – X60 (L415) – X65 (L450)
DIMENSION: FROM 1/4” UP TO 24”
API 5L PSL 2 Welded Pipe: B (L245) – X42 (L290) – X52N (L360) – X60 (L415) – X65 (L450) – X70 (L485) – X80 (L555)
DIMENSION: FROM 1/2” UP TO 60”
Weld Alternatives: ERW, HF, DSAW/SAWL, SMLS, HSAW
PSL 2 Pipe Product Specification Level: API 5L PSL 2 PSL 2, API 5L PSL 2 PSL 1
Additional Services: Internal Coating
API 5L Grade B Hot Selling Grades: API 5L X42 Pipe, API 5L X46 Pipe, API 5L X52 Pipe, API 5L X56 Pipe, API 5L X60 Pipe, API 5L X65 Pipe, API 5L X70 Pipe
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Carbon Steel API 5L Grade X42 Pipes from Rithav Pipes and Tubes ensures outstanding corrosion resistance, high strength, and durability. Our Pipe is designed for diverse industrial applications, delivering reliability and performance in challenging environments while maintaining competitive pricing.
Rithav Pipes and Tubes is one of the largest Carbon Steel API 5L Grade X42 Pipes suppliers in Delhi, India, providing a comprehensive range of high-quality pipes tailored for various industries, ensuring reliable delivery and exceptional service to meet diverse project needs.
Yes, we offer custom sizes for Carbon Steel API 5L Grade X42 Pipes to meet your specific requirements. Our team at Rithav Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@rithavpipesandtubes.co.in.
Carbon Steel API 5L Grade X42 Pipes find extensive use in oil and gas pipelines, natural gas distribution, refineries, petrochemical facilities, and power plants. They are ideal for transmitting fluids and gases, as well as for structural applications and subsea piping where durability, strength, and corrosion resistance are crucial. X42 pipes are also employed in hydrocarbon transportation, water pipelines, and offshore drilling platforms. With options for anti-corrosion coatings like 3LPE, FBE, or galvanized finishes, API 5L X42 pipes ensure long-lasting performance in harsh and high-pressure environments, making them a top choice for critical infrastructure projects.
