Home > Carbon Steel > Carbon Steel DIN 17172 Pipe
Rithav Pipes and Tubes, based in Delhi, India, stands out as a top manufacturer and supplier of Carbon Steel DIN 17172 Pipes. We provide high-performance solutions designed for pipelines that operate under high pressure and in challenging environmental conditions. Our pipes meet the DIN 17172 specifications, making them perfect for transporting gas, oil, and water in both above-ground and underground systems. Crafted with precision and a commitment to quality, our DIN 17172 pipes boast excellent mechanical strength, weldability, and resistance to corrosion. Rithav Pipes and Tubes serves major infrastructure, energy, and petrochemical projects across India and beyond, delivering reliable and cost-effective piping solutions.
Our Carbon Steel DIN 17172 Pipes are typically made from steel grades such as StE 210.7, StE 240.7, StE 290.7, and StE 360.7. These grades include carbon (up to 0.22%), manganese (up to 1.60%), and carefully controlled levels of phosphorus and sulfur. The pipes provide tensile strength ranging from 360 to 510 MPa and yield strength between 210 to 360 MPa, depending on the specific grade. They also exhibit good elongation, toughness, and weldability, making them perfect for transporting pressurized fluids and for use in high-stress pipeline systems in tough and variable environments.
| Standards | DIN 17172 StE 360.7 Pipe |
|---|---|
| Welded Pipe Size | 5.0 mm – 1219.2 mm |
| Seamless Pipe Size | 4 to 219mm W. T.: 0.5 to 20mm |
| EFW Pipe size | 5.0 mm – 1219.2 mm |
| Pipe Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Tube Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Welded Tube Size | 6.35 mm OD To 152 mm OD |
| Length | Single Random, Double Random, Standard & Cut length Pipe & Tube |
| Tube wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Application | Oil Pipe & Tube, Gas Pipe & Tube, Fluid Pipe & Tube, Boiler Pipe & Tube, Heat exchanger Tube |
| Type | Welded, Seamless, ERW, EFW, Fabricated Pipe, ‘U’ bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Tube etc |
| Test Certificate | Manufacturer Test Certificate Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection |
| Form | Round, Hydraulic, ‘U’ bent or Hollow,LSAW, Boiler, Straight Pipe, Clad Pipe, Rectangular, Square Pipe Etc |
| End | Plain End, Beveled End, Treaded Pipe & Tube |
| Marking | All Tubes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| We can also cut, thread, and groove Tubes to meet your specifications | |
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
|---|---|---|---|---|---|---|---|---|---|
| max 0.22 | max 0.55 | 0.90 – 1.50 | 0.04 | 0.035 | – | – | – | – | – |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 630 | – | – | 20 | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Carbon Steel DIN 17172 pipes from Rithav Pipes and Tubes means investing in quality, reliability, and industry expertise. As a leading manufacturer and supplier in Delhi, India, we adhere to stringent quality standards, delivering pipes that provide exceptional strength, durability, and performance in demanding applications. Our DIN 17172 pipes are ideal for high-pressure environments in the oil and gas, chemical processing, and power generation sectors. With competitive pricing, timely delivery, and dedicated customer support, Rithav Pipes and Tubes is the trusted choice for all your piping needs.
Rithav Pipes and Tubes is one of the largest Carbon Steel DIN 17172 Pipe suppliers in Delhi, India, providing a comprehensive range of high-quality pipes tailored for various industries, ensuring reliable delivery and exceptional service to meet diverse project needs.
Yes, we offer custom sizes for Carbon Steel DIN 17172 Pipe to meet your specific requirements. Our team at Rithav Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@rithavpipesandtubes.co.in.
Carbon Steel DIN 17172 Pipes are commonly utilized for transporting gas, oil, and water in both municipal and industrial pipeline networks. They play a crucial role in cross-country transmission lines, city gas distribution systems, water treatment facilities, and industrial fluid pipelines. Their robust design allows them to endure high pressure and environmental stress, making them ideal for refineries, chemical plants, and power generation infrastructure. With their strong mechanical properties, corrosion resistance, and excellent weldability, these pipes ensure long-lasting and cost-effective performance, supporting essential utility, energy, and engineering applications around the globe.
