Home > Carbon Steel > Carbon Steel EN10025 Pipe
Rithav Pipes and Tubes, based in Delhi, India, stands out as a top manufacturer and supplier of Carbon Steel EN10025 Pipes. Known for their commitment to quality, Rithav caters to a wide range of industries, including construction, infrastructure, oil & gas, and engineering. The company prides itself on delivering products that not only meet international standards but are also designed for strength, durability, and performance. With cutting-edge manufacturing processes and a robust distribution network, Rithav guarantees timely deliveries and exceptional customer service, earning its reputation as a reliable name in the carbon steel pipe sector, both at home and abroad.
Carbon Steel EN10025 Pipes generally consist of carbon (up to 0.22%), manganese (up to 1.60%), silicon (up to 0.55%), along with trace amounts of sulfur and phosphorus. These pipes adhere to the EN 10025 standard, which ensures impressive mechanical properties, including a minimum yield strength ranging from 235 to 355 MPa and tensile strength between 360 and 630 MPa, depending on the specific grade (like S235, S275, or S355). The material is known for its excellent weldability, impact resistance, and structural integrity, making it perfect for load-bearing and high-pressure applications in demanding environments.
| Standard | AISI, DIN, EN, GB, IS, JIS, ASTM, ASME Pipe |
|---|---|
| Steel Grade En 10025 Seamless Pipe Size | 4 to 219mm W. T.: 0.5 to 20mm |
| EN 10025 Grade S355J2G3 Welded Pipe Size | 5.0 mm – 1219.2 mm |
| EN 10025 Gr S355J2G3 EFW Pipe size | 5.0 mm – 1219.2 mm |
| Steel En 10025-2-s235jr+ar Tube Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| En 10025 S235jr Pipe Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| En 10025 S275jr Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| Steel En 10025-2-s235jr+ar Welded Tube Size | 6.35 mm OD To 152 mm OD |
| En 10025-2 S275jr Steel Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| S235jr+c En 10025 Tube wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| S460ml En 10025-4 Carbon Steel Length | Single Random, Double Random, Standard & Cut length Pipe & Tube |
| En 10025-3 S355nl Steel Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Din En 10025 W.1. 1.0577 Form | Round, Hydraulic, ‘U’ bent or Hollow,LSAW, Boiler, Straight Pipe, Clad Pipe, Rectangular, Square Pipe Etc |
| EN 10025 Grade S355J2G3 Type | Welded, Seamless, ERW, EFW, Fabricated Pipe, ‘U’ bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Tube etc |
| En 10025-5 Corten End | Plain End, Beveled End, Treaded Pipe & Tube |
| Steel Grade En 10025 Marking | All En 10025 Mild Steel Pipes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| En 10025 Grade S355j2g3 CS Application | Oil Pipe & Tube, Gas Pipe & Tube, Fluid Pipe & Tube, Boiler Pipe & Tube, Heat exchanger Tube |
| EN 10025 Gr S355J2G3 Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| En 10025 Grade S355j2g3 Carbon Steel Specialize in |
|
| Material Test Certificates (MTC) | Material Test Certificates (MTC) as per EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2, 100% Radiography Test Report, Raw Materials Certificate, Third Party Inspection Report, Fumigation Certificates, Heat Treatment Charts, Din En 10025 W.1. 1.0577 Pipe HS Code Commercial Invoice, Form A for Generalized System of Preferences (GSP) |
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
|---|---|---|---|---|---|---|---|---|---|
| max 0.20 | max 0.55 | max 1.60 | 0.035 | 0.035 | – | – | – | – | – |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 490 | 630 | – | – | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| 1/8″ IPS(.405″ O.D.) | 3 1/2″ IPS( 4.000″ O.D.) |
|---|---|
| SCH 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/4″ IPS(.540″ O.D.) | 4″ IPS(4.500″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 3/8″ IPS(.675″ O.D.) | 5″ IPS( 5.563″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/2″ IPS(.840″ O.D.) | 6″ IPS(6.625″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 3/4″ IPS(1.050″ O.D.) | 8 ” IPS(8.625″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 1″ IPS:(1.315′ O.D.) | 10″ IPS(10.750″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 10, 20, 40, 80 (.500), TRUE 80(.500) |
| 1-1/4″ IPS(1.660″ O.D.) | 12″ IPS(12.750″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500) |
| 1-1/2″ IPS(1.900″ O.D.) | 14″ IPS(14.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10 (.188), SCH40 (.375) |
| 2″ IPS(2.375″ O.D.) | 16″ IPS(16.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10(.188), SCH40(.375) |
| 2 1/2″ IPS(2.875″ O.D.) | 18″ IPS (18.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH-40 (.375) |
| 3″ IPS( 3.500″ O.D.) | |
| SCH 5, 10, 40, 80, 160, XXH |
Choosing Carbon Steel EN10025 Pipe from Rithav Pipes and Tubes ensures outstanding corrosion resistance, high strength, and durability. Our Pipe is designed for diverse industrial applications, delivering reliability and performance in challenging environments while maintaining competitive pricing.
Rithav Pipes and Tubes is one of the largest Carbon Steel EN10025 Pipe suppliers in Delhi, India, providing a comprehensive range of high-quality pipes tailored for various industries, ensuring reliable delivery and exceptional service to meet diverse project needs.
Yes, we offer custom sizes for Carbon Steel EN10025 Pipe to meet your specific requirements. Our team at Rithav Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@rithavpipesandtubes.co.in.
Carbon Steel EN10025 Pipes find extensive use in structural and engineering projects due to their remarkable strength and toughness. They’re crucial in constructing building frames, bridges, and various infrastructure projects. In the energy sector, these pipes are integral to oil & gas pipelines and pressure vessels. Their weldability and durability also make them suitable for heavy machinery, automotive frames, and shipbuilding. Furthermore, EN10025 pipes are preferred in the construction of industrial plants, warehouses, and railway infrastructure. Their adherence to international standards guarantees safety, reliability, and longevity in both high-stress and everyday industrial settings.
