Home > Carbon Steel > Carbon Steel EN10305-1 Pipes
With its main office in Houston, USA, Liam Pipes and Tubes is a top producer and supplier of Carbon Steel EN10305-1 Pipes, which are designed for precision applications needing excellent surface quality and strict dimensional tolerances. These seamless, cold-drawn tubes are perfect for mechanical engineering applications, hydraulic systems, and automobile parts. Our pipes are manufactured in compliance with EN 10305-1 and provide excellent machinability, uniform structure, and high strength. Liam Pipes and Tubes provides trustworthy carbon steel piping solutions to a variety of industries in the USA and abroad thanks to its state-of-the-art production facilities and dedication to quality and dependability.
EN10305-1 Carbon Steel Low-carbon steel grades like E235 or E355, which contain carbon (≤0.22%), manganese (≤1.60%), phosphorus (≤0.025%), and sulphur (≤0.025%), are commonly used to make pipes. Excellent surface finish and dimensional accuracy are provided by these cold-drawn seamless tubes. Depending on the grade, mechanical properties include a tensile strength of 340–580 MPa and a yield strength of 235–355 MPa. They also have outstanding formability and good elongation (≥22%). These pipes are appropriate for precision engineering applications needing reliable performance and high pressure tolerance because the cold-drawing process increases the material’s strength and homogeneity.
| DIN | EN | BS | NFA | ASTM | ASME |
| – | EN 10305-1 Grade E355 | – | – | – | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Carbon Steel EN10305-1 Pipes from Rithav Pipes and Tubes ensures outstanding corrosion resistance, high strength, and durability. Our Pipe is designed for diverse industrial applications, delivering reliability and performance in challenging environments while maintaining competitive pricing.
| Pipe types | CHEMICAL COMPOSITION (LADLE ANALYSIS) | ||||||||||
| C% | Si% | Mn% | P% | S% | Cr% | Mo% | V% | Inne% | Cr+ Mo+ Ni Max% | Al.% | |
| E235 | <\=0,17 | <\=0,35 | <\=1,20 | <\=0,025 | <\=0,025 | – | – | – | – | – | 0,020- 0,060 |
| E255 | <\=0,21 | <\=0,35 | 0,40-1,10 | <\=0,025 | <\=0,025 | – | – | – | – | – | 0,020- 0,060 |
| E355 | <\=0,22 | <\=0,55 | <\=1,60 | <\=0,025 | <\=0,025 | – | – | – | – | – | 0,020- 0,060 |
| C35E | 0,32-0,39 | <\=0,40 | 0,50-0,80 | 0,035 | <\=0,035 | <\=0,40 | <\=0,10 | – | – | 0,63 | – |
| C45E | 0,42-0,55 | <\=0,40 | 0,50-0,80 | 0,035 | <\=0,035 | <\=0,40 | <\=0,10 | – | – | 0,63 | – |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 490 | 630 | – | 22 | ||
Rithav Pipes and Tubes is one of the largest Carbon Steel EN10305-1 Pipes suppliers in Delhi, India, providing a comprehensive range of high-quality pipes tailored for various industries, ensuring reliable delivery and exceptional service to meet diverse project needs.
Yes, we offer custom sizes for Carbon Steel EN10305-1 Pipes to meet your specific requirements. Our team at Rithav Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@rithavpipesandtubes.co.in.
Applications needing high mechanical performance and tight tolerances frequently use carbon steel EN10305-1 pipes. They are frequently utilised in the automotive industry for steering components, shock absorbers, and fuel injection systems. They are crucial for precision cylinders and pressure lines in hydraulic and pneumatic systems. In mechanical engineering, these pipes are also utilised for structural components, frames, and machine parts. EN10305-1 pipes are perfect for flow control systems and other applications needing less friction and leak-proof performance under high pressure because of their smooth internal surface and exceptional dimensional accuracy.
