Home > Incoloy > Incoloy 800/800H/800HT Tubing
Brydon Pipes & Tubes is a trusted supplier of Incoloy 800-800H and 800HT tubing based in the Delhis in the India. Specializing in high quality, heat resistant tubing for demanding applications. Our Incoloy 800 series tubing provides strength high strength and stability. At high temperatures Ideal for chemical processes, power generation, petrochemical and other industries. With a commitment to quality and customization we offer a wide range of sizes and grades of tubing designed to meet the unique needs of high temperature and wet environments.
Incoloy 800-800H and 800HT tubing is manufactured primarily from nickel, steel and chromium, with controlled amounts of carbon and aluminium. This unique blend provides excellent resistance to oxidation, carburization, and other high-temperature reactions. Technically 800 Series tubing retains high tensile strength, creep resistance and stability under stress at high temperatures, especially in the 800H and 800HT grades Advantages of Incoloy 800 Series tubing include excellent durability, not difficult to maintain, and suitable for high temperature applications. Nick processing -Ideal for use in petrochemical and power generation industries.
Specifications ASTM B407, B514, B515 / ASME SB407, SB514, SB515
Dimensions ASTM, ASME and API
Size Range 15″NB – 150″NB
Outer Diameter 6.35 mm OD upto 254 mm OD in 0.6 TO 20 mm thickness.
Schedule SCH 10, SCH20, SCH30, SCH40, STD, SCH60, XS, SCH80, SCH120, SCH140, SCH160, XXS
Type Seamless / ERW / Welded / Fabricated / LSAW Pipes
Length Single Random, Double Random & Cut Length
Form Round Pipes/Tubes, Square Pipes/Tubes, Rectangular Pipe/Tubes, Coiled Tubes, “U” Shape, Pan Cake Coils, Hydraulic Tube
Grade 800 / 800H / 800HT UNS (N08800, N08810, N08811), DIN (1.4876, 1.4958, 1.4959)
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST | OR |
| Incoloy 800 | N08800 | 1.4876 | Z8NC32-21 | X10NiCrAlTi32-20 | NCF 800 | NA 15 | ЭИ670 | XH32T |
| Incoloy 800H | N08810 | 1.4958 | Z8NC32-21 | X10NiCrAlTi32-20 | NCF 800H | NA 15(H) | ЭИ670 | XH32T |
| Incoloy 800HT | N08811 | 1.4959 | – | X8NiCrAlTi32-21 | NCF 800HT | NA 15(HT) | ЭИ670 | XH32T |
| Element | Alloy 800 | Alloy 800H | Alloy 800HT |
| C | 0.10 max | 0.05 – 0.10 | 0.06 – 0.10 |
| Mn | 1.50 max | 1.50 max | 1.50 max |
| Si | 1.00 max | 1.00 max | 1.00 max |
| S | 0.015 max | 0.015 max | 0.015 max |
| Cu | 0.75 max | 0.75 max | 0.75 max |
| Fe | 39.50 min | 39.50 min | 39.50 min |
| Ni | 30.00 – 35.00 | 30.00 – 35.00 | 30.00 – 35.00 |
| Cr | 19.00 – 23.00 | 19.00 – 23.00 | 19.00 – 23.00 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Incoloy 800/800H/800HT Tubes from Rithav Pipes and Tubes ensures superior quality and durability, offering outstanding corrosion resistance and high strength. Our dedication to delivering exceptional service and reliable products guarantees customer satisfaction across a wide range of industrial applications. With our expertise in Incoloy solutions, you can trust us to provide a top-tier, customized piping solution that meets your specific requirements.
Rithav Pipes and Tubes, one of the largest suppliers of Incoloy 800/800H/800HT Tubing in the Delhis, India. Offers a wide range of high-quality pipes and tubes designed for various industrial applications. Their extensive inventory and dedication to exceptional service make them a trusted choice for Incoloy products in the region, delivering reliable solutions to meet diverse project requirements.
| Element | Incoloy Alloy 800/800H/800HT |
| Density | 7.94 g/cm3 |
| Melting Point | 1385 °C (2525 °F) |
| Tensile Strength | Psi – 75,000 , MPa – 520 |
| Yield Strength (0.2%Offset) | Psi – 30,000 , MPa – 205 |
| Elongation | 30 % |
Yes, we provide custom sizes for Incoloy 800/800H/800HT Tubes to meet your specific requirements. At Rithav Pipes and Tubes, our team is dedicated to delivering tailored solutions for all your piping and tubing needs. For more information, please contact us at sales@rithavpipesandtubes.co.in.
Incoloy 800-800H and 800HT Tubing is essential for applications requiring high temperature and corrosion resistance. In the petrochemical industry it is used in heat exchanger process piping where it resists carburization and oxidation at high temperatures. In the chemical industry this device is ideal for equipment exposure to aggressive media while maintaining integrity under stress. It also powers the super heater and re-heater tubing in the boilers. Its strength and resistance to thermal fatigue make Incoloy 800 Series tubing ideal for applications where long-term performance and reliability are important.
