Home > Incoloy > Incoloy 825 Tubing
Rithav Pipes and Tubes stands out as a top manufacturer and supplier of Incoloy 825 Tubing in Delhi, India. We’re recognized for providing high-quality, corrosion-resistant solutions tailored for various industrial applications. Our expertise lies in high-performance alloy tubing, specifically designed to thrive in harsh environments like chemical processing, marine, and offshore systems. With a strong focus on quality, timely delivery, and compliance with international standards, we’ve earned the trust of clients both in India and around the world. At Rithav, we blend cutting-edge manufacturing techniques with rigorous quality control to guarantee exceptional performance and durability in every Incoloy 825 tubing product we offer.
Incoloy 825 Tubing is crafted from a nickel-iron-chromium alloy, enhanced with molybdenum, copper, and titanium. Its typical makeup consists of about 38–46% nickel, 19.5–23.5% chromium, 2.5–3.5% molybdenum, 1.5–3% copper, and the rest being iron. This alloy is known for its outstanding resistance to both reducing and oxidizing acids, as well as stress-corrosion cracking and pitting. On the mechanical side, Incoloy 825 tubing boasts a tensile strength of roughly 85 ksi (586 MPa) and a yield strength of 35 ksi (241 MPa), along with impressive elongation and impact resistance. These characteristics make it perfect for demanding industrial settings where chemical and mechanical stability are essential.
| Standard Specification | ASTM B163 UNS N08825, ASTM B516 UNS N08825 / ASME SB 163, SB 516 Seamless Superheater, Condenser, Hydraulic, Boiler and Heat-Exchanger Tubes |
| Shapes | Incoloy 825 Round, Rectangular, Square, Hydraulic, Straight, “U” Shape, Coiled, Honed Tubes, Pan Cake Coils |
| Manufacturing Type | Seamless / ERW / Welded / Fabricated / CDW / CDS / DOM / CEW / 100% X Ray Welded |
| Delivery Condition | Annealed and Pickled (AP), Polished, Bright Annealed (BA), Cold Drawn, MF |
| Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Thickness Range | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXH, SCH XXS, SCH XS |
| Standard | SUS, JIS, AISI, ASTM, GB, DIN, EN |
| Value Added Services |
|
| END | Plain End, Beveled End, Treaded 825 Incoloy Tube |
| Processing Service | Bending, Welding, Decoiling, Punching, Cutting, Moulding |
| Technique | Incoloy Alloy 825 Cold drawn, Cold rolled, Hot rolled, Extrusion Tube |
| Marking |
|
| Test Certificate |
|
| ASTM B163 Alloy 825 Tubing Packaging | Packed in PE Fabric Bundles or ply wooden box wrapped in plastic or Standard seaworthy export packing or as per customers’ request |
|
Properties |
Metric |
Imperial |
|
|
Thermal expansion co-efficient (at 20-100°C/68-212°F) |
14 µm/m°C |
7.78 µin/in°F |
|
|
Thermal conductivity |
11.1 W/mK |
77 BTU in/hr.ft².°F |
|
| Alloy | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| 825 | 0.05 max | 1.00 max | 0.05 max | 0.03 max | 1.50 – 3.00 | 22.00 min | 38.00 – 46.00 | 19.50 – 23.50 | 0.02 max | 0.06 – 1.20 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Incoloy 825 Tubes from Rithav Pipes and Tubes ensures superior quality and durability, offering outstanding corrosion resistance and high strength. Our dedication to delivering exceptional service and reliable products guarantees customer satisfaction across a wide range of industrial applications. With our expertise in Incoloy solutions, you can trust us to provide a top-tier, customized piping solution that meets your specific requirements.
Rithav Pipes and Tubes, one of the largest suppliers of Incoloy 825 Tubing in the Delhis, India. Offers a wide range of high-quality pipes and tubes designed for various industrial applications. Their extensive inventory and dedication to exceptional service make them a trusted choice for Incoloy products in the region, delivering reliable solutions to meet diverse project requirements.
| Incoloy | Density | Melting Range | Tensile Stress | Yield Stress (0.2%Offset) | Elongation |
| 825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30 % |
| ALLOY | WERKSTOFF NR./ DIN | UNS | JIS | BS | GOST | AFNOR | EN | OR |
| Incoloy 825 | 2.4858 | N08825 | NCF 825 | NA 16 | ЭП703 | NFE30C20DUM | NiCr21Mo | XH38BT |
Yes, we provide custom sizes for Incoloy 825 Tubes to meet your specific requirements. At Rithav Pipes and Tubes, our team is dedicated to delivering tailored solutions for all your piping and tubing needs. For more information, please contact us at sales@rithavpipesandtubes.co.in.
Incoloy 825 Tubing finds its place in industries that require exceptional corrosion resistance, especially in environments involving sulfuric and phosphoric acids. You’ll commonly see it used in heat exchangers, condenser tubes, offshore piping systems, nuclear fuel reprocessing, and pollution-control equipment. The alloy’s ability to resist crevice corrosion and intergranular attack makes it a go-to choice for marine and chemical plants. Additionally, Incoloy 825 is utilized in acid production facilities, oil and gas recovery systems, and pickling equipment. Its performance in these challenging applications underscores
