Home > Incoloy > Incoloy Boiler Tubing
Rithav Pipes and Tubes, a Delhi-based India, is a leading manufacturer and supplier of Incoloy Boiler Tubing, recognized for providing high-performance products to serve extreme industrial needs. Designed from advanced nickel-iron-chromium alloys, our tubing is produced according to ASTM B407, ASTM B163, and other international standards to provide uniform wall thickness, even internal surfaces, and stable performance in extreme heat. We supply markets like power generation, chemical processing, refineries, and petrochemical plants with tubing solutions resistant to high-pressure steam, oxidation, and corrosion, with long life and low maintenance.
The Incoloy Boiler Tubing consists of nickel, chromium, and iron and has molybdenum and copper added in order to increase its resistance to corrosion, oxidation, and high-temperature deterioration. Mechanically, the tubing has high tensile strength, good ductility, and high resistance to thermal fatigue and creep. It retains structural integrity under cyclic thermal conditions and thus is appropriate for high-pressure and high-temperature boiler systems. Outstanding scaling, oxidation, and aggressive media resistance are some of its key benefits, which make it a reliable material for heat-intensive and corrosive industrial processes.
| Boiler Tube Standard | ASTM B423, B739 / ASME SB423, SA516 |
| Seamless Boiler Tube Sizes | 1 / 2″ NB – 16″ NB |
| Welded Boiler Tube Sizes | 1 / 2″ NB – 24″ NB |
| Boiler Tube Outside Diameter | 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock, OD Size Steel Boiler Tubes available Ex-stock |
| Boiler Tube Manufacturing Process | Seamless / Welded / ERW |
| Incoloy Boiler Tube Schedule | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Boiler Tube Length | Single Random, Double Random, Standard & Cut length |
| Delivery Condition | Annealed and Pickled, Polished, Bright Annealed, Cold Drawn |
| Outside Finish | 2B, No.4, No.1, No.8 Mirror Finish for Incoloy Boiler Tubes, Finish as per customer Requirements |
| Value Added Services | Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Incoloy | 0.05 max | 1.00 max | 0.5 max | 0.03 max | 1.50 – 3.00 | 22.00 min | 38.00 – 46.00 | 19.50 – 23.50 | 0.02 max | 0.06 – 1.20 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Incoloy Boiler Tubes from Rithav Pipes and Tubes ensures superior quality and durability, offering outstanding corrosion resistance and high strength. Our dedication to delivering exceptional service and reliable products guarantees customer satisfaction across a wide range of industrial applications. With our expertise in Incoloy solutions, you can trust us to provide a top-tier, customized piping solution that meets your specific requirements.
Rithav Pipes and Tubes, one of the largest suppliers of Incoloy Boiler Tubing in the Delhis, India. Offers a wide range of high-quality pipes and tubes designed for various industrial applications. Their extensive inventory and dedication to exceptional service make them a trusted choice for Incoloy products in the region, delivering reliable solutions to meet diverse project requirements.
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Incoloy 825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30 % |
| BWG | BWG | BWG | BWG | BWG | BWG | BWG | BWG | ||
| 25 | 22 | 20 | 18 | 16 | 14 | 12 | 10 | ||
| WT mm | WT mm | WT mm | WT mm | WT mm | WT mm | WT mm | WT mm | ||
| Outside Diameter | Outside Diameter | 0.508 | 0.711 | 0.889 | 1.245 | 1.651 | 2.108 | 2.769 | 3.404 |
| mm | inch | kgs/m | kgs/m | kgs/m | kgs/m | kgs/m | kgs/m | kgs/m | |
| 6.35 | 1/4 | 0.081 | 0.109 | 0.133 | 0.174 | 0.212 | |||
| 9.53 | 3/8 | 0.126 | 0.157 | 0.193 | 0.257 | 0.356 | 0.429 | ||
| 12.7 | 1/2 | 0.214 | 0.263 | 0.356 | 0.457 | 0.612 | 0.754 | ||
| 15.88 | 5/8 | 0.271 | 0.334 | 0.455 | 0.588 | 0.796 | 0.995 | ||
| 19.05 | 3/4 | 0.327 | 0.405 | 0.553 | 0.729 | 0.895 | 1.236 | ||
| 25.4 | 1 | 0.44 | 0.546 | 0.75 | 0.981 | 1.234 | 1.574 | 2.05 | |
| 31.75 | 1 1/4 | 0.554 | 0.688 | 0.947 | 1.244 | 1.574 | 2.014 | 2.641 | |
| 38.1 | 1 1/2 | 0.667 | 0.832 | 1.144 | 1.514 | 1.904 | 2.454 | 3.233 | |
| 44.5 | 1 3/4 | 1.342 | 1.774 | 2.244 | 2.894 | 3.5 | |||
| 50.8 | 2 | 1.549 | 2.034 | 2.574 | 3.334 | 4.03 | |||
| 63.5 | 2 1/2 | 1.949 | 2.554 | 3.244 | 4.214 | 5.13 | |||
| 76.2 | 3 | 2.345 | 3.084 | 3.914 | 5.094 | 6.19 | |||
| 88.9 | 3 1/2 | 2.729 | 3.609 | 4.584 | 5.974 | 7.27 | |||
| 101.6 | 4 | 4.134 | 5.254 | 6.854 | 8.35 | ||||
| 114.3 | 4 1/2 | 4.654 | 5.924 | 7.734 | 9.43 |
Yes, we provide custom sizes for Incoloy Boiler Tubes to meet your specific requirements. At Rithav Pipes and Tubes, our team is dedicated to delivering tailored solutions for all your piping and tubing needs. For more information, please contact us at sales@rithavpipesandtubes.co.in.
Incoloy Boiler Tubing is extensively applied in industries that require high performance in severe temperature and corrosive environments. In power generation, it is applied in boilers, steam generators, and superheaters, where oxidation resistance and thermal cycling are excellent. In chemical processing, the tubing finds application in conveying reactive fluids in corrosive conditions, sustaining efficiency as well as system safety. It is also critical in gas processing units, petrochemical refineries, and waste heat recovery systems, where its reliability and service life cut down operating expenses. Its stress resistance makes it perfect for high-temperature critical heat transfer systems.
