Rithav Pipes and Tubes is a reputable manufacturer and supplier of Monel Coil Tubing based in Delhi, India. We take pride in delivering high-performance alloy products, focusing on Monel coil tubing that’s built to endure tough industrial conditions. Our tubing is crafted with precision, ensuring top-notch quality, durability, and resistance to corrosion. With a wealth of industry experience, Rithav Pipes and Tubes serves various sectors, including chemical processing, marine engineering, and oil & gas. As a leading supplier in India, we are dedicated to providing reliable solutions that adhere to international standards for both local and global markets.
Monel Coil Tubing is primarily made up of nickel (63%-70%) and copper (20%-29%), along with trace amounts of iron, manganese, carbon, and silicon. This nickel-copper alloy is known for its outstanding resistance to seawater, acids, and alkaline solutions. Monel tubing boasts impressive mechanical properties, featuring tensile strength between 550 MPa and 620 MPa, a minimum yield strength of 240 MPa, and at least 35% elongation. With a high melting point of around 1,350°C and a density of 8.8 g/cm³, it’s perfect for high-temperature and pressure applications. The blend of toughness and corrosion resistance guarantees exceptional performance in challenging environments.
| End | Plain End, Beveled End, Treaded |
|---|---|
| Monel Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| Monel Welded Tube Size | 6.35 mm OD To 152 mm OD |
| Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Monel tubing wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| Specialize in | Monel Capillary Tube & Other Odd Size Monel Heat Exchanger & Condenser Tubes |
| Monel Tube Standards | ASTM B163, ASTM B730 /ASME SB163, ASME SB730 |
| Test Certificate | Manufacturer Test Certificate Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection |
| Monel tube Form | Round, Coil, Square, Rectangular, Boiler, Hydraulic, Straight or ‘U’ bent Tubes, Hollow, LSAW Tubes Etc. |
| Monel Tube Type | Seamless, ERW, EFW, Welded, Fabricated |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Marking | All Monel Alloy tubes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Application | Oil Tube, Gas Tube, Fluid Tube, Boiler and Heatexchanger |
| Monel Alloy Tube Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Monel Alloy tube Length | Single Random, Double Random, Standard & Cut length |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.24max | 28.0-34.0 | 2.50 max | 63.00 min | – |
| Alloy K500 | 0.25 max | 1.50 max | 0.50 max | 0.010max | 27.00 – 33.00max | 0.5 – 2 | 63.00 min | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Alloy 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
| Monel K500 | 8.44g\cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20% |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Monel Coil Tubing from Rithav Pipes and Tubes ensures exceptional corrosion resistance, high strength, reliable performance, and superior durability for optimal solutions in various industrial applications.
Rithav Pipes and Tubes, one of the largest suppliers of Monel Coil Tubing in Delhi, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for monel products in the region.
Yes, we offer custom sizes for Monel Coil Tubing to meet your specific requirements. Our team at Rithav Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@rithavpipesandtubes.co.in.
Monel Coil Tubing is extensively used in industries where resistance to harsh chemicals and marine conditions is essential. It’s particularly well-suited for oil and gas production, heat exchangers, chemical processing plants, and seawater systems. The tubing’s ability to resist corrosion and stress cracking makes it a top choice for offshore platforms, hydraulic lines, and instrumentation. The aerospace and marine engineering sectors also reap the benefits of Monel coil tubing due to its strength and versatility. Rithav Pipes and Tubes provides Monel coil tubing that meets stringent quality standards, making it ideal for critical and high-performance applications.
