Rithav Pipes and Tubes has made a name for itself as a leading manufacturer and supplier of Monel Tubing in Delhi, India. We specialize in crafting high-quality nickel-copper alloy products, delivering top-notch Monel tubing that adheres to strict international standards. Our Monel Tubes are in high demand due to their remarkable corrosion resistance, durability, and outstanding mechanical strength. We cater to various industries, including marine, chemical, and oil & gas, ensuring our products perform reliably even in the toughest conditions. As a trusted supplier, Rithav Pipes and Tubes is committed to offering cost-effective and efficient solutions for clients both in India and around the globe.
Monel Tubing is primarily made up of nickel (63-70%) and copper (20-29%), along with trace amounts of iron, manganese, carbon, and silicon. This unique blend gives it exceptional resistance to seawater and acidic environments. Monel boasts a tensile strength of about 550-620 MPa, a yield strength of 240-345 MPa, and a minimum elongation of 40%, depending on the specific grade. With a density of 8.8 g/cm³ and a melting point between 1,300–1,350°C, this alloy maintains its mechanical properties across a wide temperature range, making Monel Tubing perfect for critical applications that demand toughness and reliability.
| End | Plain End, Beveled End, Treaded |
|---|---|
| Monel Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| Monel Welded Tube Size | 6.35 mm OD To 152 mm OD |
| Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Monel tubing wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| Specialize in | Monel Capillary Tube & Other Odd Size Monel Heat Exchanger & Condenser Tubes |
| Monel Tube Standards | ASTM B163, ASTM B730 /ASME SB163, ASME SB730 |
| Test Certificate | Manufacturer Test Certificate Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection |
| Monel tube Form | Round, Coil, Square, Rectangular, Boiler, Hydraulic, Straight or ‘U’ bent Tubes, Hollow, LSAW Tubes Etc. |
| Monel Tube Type | Seamless, ERW, EFW, Welded, Fabricated |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Marking | All Monel Alloy tubes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Application | Oil Tube, Gas Tube, Fluid Tube, Boiler and Heatexchanger |
| Monel Alloy Tube Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Monel Alloy tube Length | Single Random, Double Random, Standard & Cut length |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.24max | 28.0-34.0 | 2.50 max | 63.00 min | – |
| Alloy K500 | 0.25 max | 1.50 max | 0.50 max | 0.010max | 27.00 – 33.00max | 0.5 – 2 | 63.00 min | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Alloy 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
| Monel K500 | 8.44g\cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20% |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Monel Tubing from Rithav Pipes and Tubes ensures exceptional corrosion resistance, high strength, reliable performance, and superior durability for optimal solutions in various industrial applications.
Rithav Pipes and Tubes, one of the largest suppliers of Monel Tubing in Delhi, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for monel products in the region.
Yes, we offer custom sizes for Monel Tubing to meet your specific requirements. Our team at Rithav Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@rithavpipesandtubes.co.in.
Monel Tubing is widely utilized in industries where high corrosion resistance is a must. Its applications span marine engineering, chemical and hydrocarbon processing equipment, heat exchangers, boiler feedwater heaters, and desalination plants. Thanks to its resistance to saltwater corrosion, it’s an excellent choice for offshore oil and gas platforms and piping systems. Additionally, Monel Tubes find their place in the aerospace and nuclear sectors due to their strength and ability to withstand harsh environments. Rithav Pipes and Tubes guarantees that every Monel Tubing product meets stringent quality standards, making them a reliable option for demanding industrial applications worldwide.
