Home > Stainless Steel > Stainless steel 304H Welded Tubing
Rithav Pipes and Tubes, located in Delhi, India, has earned a solid reputation as a reliable manufacturer and supplier of top-notch stainless steel products, including Stainless Steel 304H Welded Tubing. We take pride in our dedication to quality, innovation, and ensuring our clients are satisfied. Our welded tubing solutions are crafted to meet rigorous international standards. The Stainless Steel 304H Welded Tubes we offer are designed for exceptional strength, impressive corrosion resistance, and outstanding performance even at high temperatures. With state-of-the-art manufacturing facilities and a talented team, Rithav consistently delivers high-quality tubing across various industries. We focus on timely delivery, competitive pricing, and a customer-first approach in every project.
Stainless Steel 304H Welded Tubing is composed of roughly 18-20% chromium, 8-11% nickel, and a higher carbon content (0.04–0.10%) to boost strength at elevated temperatures. It also includes manganese, silicon, and trace amounts of phosphorus and sulfur. This tubing boasts a tensile strength of about 515 MPa, a yield strength of 205 MPa, and an elongation of around 40%. The added carbon enhances creep resistance and structural stability in high-heat settings. These welded tubes also excel in oxidation resistance, ductility, and weldability, making them ideal for challenging mechanical and thermal applications.
| Specifications | : | ASTM A/ASME SA213/ A269/ A249 |
| Dimensions | : | ASTM, ASME and API |
| SS 304H Tubing Size | : | 1/8″ NB TO 30″ NB IN |
| Thickness | : | 0.35mm to 6.35mm OD in thickness ranging from 0.1mm to 1.2mm. |
| Type | : | Seamless / ERW / Fabricated / Welded / LSAW Tubes |
| Schedule | : | SCH20, SCH30, SCH40, XS, SCH60, STD, SCH80, SCH80, SCH120, SCH140, SCH160, XXS |
| Length | : | Single Random, Double Random & Cut Length. |
| Form | : | Round, Square, Rectangular, Hydraulic. |
| End | : | Plain End, Beveled End, Treaded |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 304H | 0.10 max | 2.0 max | 0.75 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 10.5 | – |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Stainless Steel 304H Welded Tubing from Rithav Pipes and Tubes for exceptional corrosion resistance, superior strength and excellent durability. Ideal for a variety of industrial applications it provides outstanding performance in harsh environments. With precision manufacturing and quality assurance, we ensure reliable and durable tubing solutions.
Rithav Pipes and Tubes is the largest supplier of Stainless Steel 304H Welded Tubing in Delhi, India. Known for its high-quality products. We offer superior corrosion resistance, strength, and durability. Trusted by industries worldwide they provide reliable precision-engineered tubing for various applications and project needs.
| STANDARD | WERKSTOFF NR. | UNS |
| SS 304H | 1.4948 | S30409 |
Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/0C) | Thermal Conductivity (W/m.K) | Specific Heat 0-1000C (J/kg.K) | Electrical Resistivity (n.m) | |||
0-1000C | 0-3150C | 0-5380C | at 1000C | at 5000C | |||||
304H | 8000 | 193 | 17.2 | 17.8 | 18.4 | 16.2 | 21.5 | 500 | 720 |
Yes, Rithav Pipes and Tubes offer large custom designs for Stainless Steel 304H Welded Tubing. With design, wall thickness and length. Their adjustable options ensure the tubing meets specific application requirements. This flexibility makes it more efficient and reliable for different industries and environments. For more details, contact us at sales@rithavpipesandtubes.co.in.
Stainless Steel 304H Welded Tubing finds its place in various industries where high-temperature strength and corrosion resistance are crucial. Common applications include heat exchangers, condensers, boilers, superheaters, and furnace components in power generation, petrochemical, and chemical processing sectors. Their durability and formability make them perfect for pharmaceutical, food processing, and marine environments. Additionally, these tubes are utilized in architectural structures and automotive exhaust systems, thanks to their sleek finish and mechanical properties.
