Home > Stainless Steel > Stainless Steel 316/316L Heat Exchanger Tubing
Rithav Pipes and Tubes, a top Delhi, India-based manufacturer and supplier of high-quality Stainless Steel 316/316L Heat Exchanger Tubing. Engineered to perform in the best possible way under corrosive and high-temperature environments, our tubing is relied upon by a broad array of industries. Our focus is on precision manufacturing, rigorous compliance with global standards, and customer-centric service. Our 316/316L tubing is engineered to satisfy stringent application requirements, providing long-lasting reliability and efficiency. For chemical processing, marine applications, or sanitary systems, Rithav provides hard-wearing, high-performance solutions to suit your heat exchanger requirements.
Stainless Steel 316/316L Heat Exchanger Tubing contains iron, 16–18% chromium, 10–14% nickel, and 2–3% molybdenum, making it highly resistant to corrosion, especially where environments are chloride-rich. The 316L grade contains low carbon, which improves weldability and minimizes the possibility of precipitation of carbides. The tubes possess excellent tensile strength of up to 580 MPa, coupled with good formability and ductility under stress. The main benefits are resistance to pitting and crevice corrosion, high-temperature workability, and long-term stability of structure, making them perfect for severe, corrosive, and thermally stressful applications.
Range : 10 mm OD to 50.8 mm OD
Outer Diameter : 6.00 mm to 101.60 mm
Wall Thickness : 0.70 mm to 8.00 mm
Length : up to 20 m (65.62 ft) Length & Customed Required Length
Specifications : ASTM A 213, A 268, A 269, A 789, Equivalent to ASME, EN, JIS Etc.
| Element | SS 316 | SS 316L |
| C | 0.08 max | 0.035 max |
| Mn | 2.0 max | 2.0 max |
| Si | 1.0 max | 1.0 max |
| P | 0.045 max | 0.045 max |
| S | 0.030 max | 0.030 max |
| Cr | 16.00 – 18.00 | 16.00 – 18.00 |
| Mo | 2.00 – 3.00 | 2.00 – 3.00 |
| Ni | 11.00 – 14.00 | 10.00 – 14.00 |
| Fe | 67.845 min | 68.89 min |
| Element | SS 316 | SS 316L |
| Density | 8.0 g/cm3 | 8.0 g/cm3 |
| Melting Point | 1400 °C (2550 °F) | 1399 °C (2550 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 | Psi – 30000 , MPa – 205 |
| Elongation | 35 % | 35 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Stainless Steel 316/316L Heat Exchanger Tubing from Rithav Pipes and Tubes ensures access to high-quality materials tailored for durability and performance. With a commitment to excellence, Brydon offers precise dimensions and superior corrosion resistance, making their tubing ideal for challenging environments. The company’s expertise in manufacturing guarantees reliability and compliance with industry standards. Additionally, Brydon’s dedicated customer service provides personalized support, ensuring clients find the right solutions for their specific needs. Trust Rithav Pipes and Tubes for unparalleled quality and performance in stainless steel heat exchanger tubing.
Rithav Pipes and Tubes, one of the largest suppliers of Stainless Steel 316/316L Heat Exchanger Tubing in Delhi, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
Yes, we offer custom sizes for Stainless Steel 316/316L Heat Exchanger Tubing to meet your specific requirements. Our team at Rithav Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@rithavpipesandtubes.co.in.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | – | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
Stainless Steel 316/316L Heat Exchanger Tubing is widely applied in corrosive environments where sanitation, corrosion resistance, and thermal stability are essential. It is suited for chemical plants, oil and gas production, and marine systems particularly where chloride-induced corrosion is of concern. In the food and beverage and pharmaceutical sectors, 316/316L tubing guarantees sanitary compliance and durable cleanliness. Some other applications are HVAC equipment, power generation units, and desalination plants, where there is the need for efficient heat transfer and resistance to scaling and contamination. Its reliability and versatility make it a material that is used across various industries.
