Home > Stainless Steel > Stainless Steel 316Ti Heat Exchanger Tubing
Rithav Pipes and Tubes, a reputable manufacturer and supplier based in Delhi, India, specializes in high-performance Stainless Steel 316Ti Heat Exchanger Tubing, perfect for tough thermal and corrosive settings. This titanium-stabilized variant of 316 stainless steel boasts superior resistance to intergranular corrosion, chloride attack, and oxidation at high temperatures. It’s an excellent choice for heat exchangers, condensers, and cooling systems, maintaining its mechanical strength and corrosion resistance even under fluctuating thermal conditions. Rithav produces both seamless and welded 316Ti tubes, adhering to ASTM A213, ASTM A269, and tailored customer specifications, ensuring top-notch quality and reliability for critical operations.
Stainless Steel 316Ti Heat Exchanger Tubing is composed of 16–18% chromium, 10–14% nickel, 2–3% molybdenum, and 0.5% titanium, which helps stabilize the alloy against carbide precipitation when exposed to high heat. The inclusion of titanium boosts resistance to intergranular corrosion while keeping weldability intact. Its mechanical properties feature a tensile strength of at least 515 MPa, yield strength of at least 205 MPa, and elongation of at least 35%. These tubes excel in both oxidizing and acidic environments and can handle continuous service temperatures up to 870°C, making them ideal for thermal cycling and high-pressure situations.
Range : 10 mm OD to 50.8 mm OD
Outer Diameter : 6.00 mm to 101.60 mm
Wall Thickness : 0.70 mm to 8.00 mm
Length : up to 20 m (65.62 ft) Length & Customed Required Length
Specifications : ASTM A 213, A 268, A 269, A 789, Equivalent to ASME, EN, JIS Etc.
| Element | SS 316TI |
| C | 0.08 max |
| Mn | 2.0 max |
| Si | 0.75 max |
| P | 0.045 max |
| S | 0.030 max |
| Cr | 16.00 – 18.00 |
| Mo | 2.00 – 3.00 |
| Ni | 10.00 – 14.00 |
| Fe | 68.395 min |
| Element | SS 316TI |
| Density | 8.0 g/cm3 |
| Melting Point | 1399 °C (2550 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Stainless Steel 316Ti Heat Exchanger Tubing from Rithav Pipes and Tubes ensures high-quality materials and precise manufacturing standards. Rithav Pipes and Tubes is known for delivering reliable tubing with superior corrosion resistance and durability, specifically designed to withstand high-temperature environments. The company offers exceptional customer support, timely delivery, and custom solutions to meet diverse project needs. Their commitment to quality and strict adherence to industry standards make them a trusted choice for heat exchanger tubing, ensuring long-lasting performance and reduced maintenance costs.
Rithav Pipes and Tubes, one of the largest suppliers of Stainless Steel 316Ti Heat Exchanger Tubing in Delhi, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
Yes, we offer custom sizes for Stainless Steel 316Ti Heat Exchanger Tubing to meet your specific requirements. Our team at Rithav Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@rithavpipesandtubes.co.in.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316TI | 1.4571 | S31635 | SUS 316Ti | 320S31 | 08Ch17N13M2T | Z6CNDT17‐123 | X6CrNiMoTi17-12-2 |
Stainless Steel 316Ti Heat Exchanger Tubing finds extensive use in chemical processing, petrochemical plants, power generation systems, and marine applications, particularly where chloride stress corrosion and high-temperature oxidation are issues. Typical applications include boiler feedwater systems, steam condensers, gas-to-liquid heat exchangers, and air-cooled cooling systems. In industries like pharmaceuticals, food processing, and dairy, these tubes are prized for their cleanability and resistance to acidic and caustic cleaning agents. Their stability and durability make them a go-to choice for demanding applications.
