Rithav Pipes and Tubes, Delhi, India, is a reliable producer and supplier of Stainless Steel 347/347H Welded Tubing. With the reputation for providing high-performance tubing solutions, Rithav caters to industries like aerospace, chemical processing, and power generation. Our tubings are produced through the latest welding technology, providing superior durability, dimensional tolerance, and weld integrity. We are dedicated to supplying corrosion- and heat-resistant tubing customized to endure harsh environments. With customer satisfaction at the core, Rithav provides quick delivery, competitive prices, and quality consistency, thus becoming an uncompromising ally for industrial stainless steel tubing needs.
Stainless Steel 347/347H Welded Tubing is an austenitic steel alloy that contains 17–19% chromium, 9–13% nickel, and 0.45% niobium, adding strength to withstand intergranular corrosion. The 347H variation, having a higher carbon concentration, enables increased creep strength and thermal stability. The tube provides a tensile strength of 515 MPa and yield strength of 205 MPa, making it ideal for high-temperature, high-stress applications. Its high weldability, in addition to resistance to carbide precipitation, guarantees stability in weldments like heat exchangers, boilers, and pressure vessels exposed to harsh conditions.
Welded Tubes Size : 1 / 8″ NB – 24″ NB
Specifications : ASTM A/ASME SA213, A249, A269, A312, A358
Standard : ASTM, ASME and API
Length : Single Random, Double Random & Required Length
Outer Diameter : 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB
Thickness : 0.3mm – 50 mm, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Types : Welded
Form : Round Tubes, Square Tubes, Rectangular Tubes, Coiled Tubes, “U” Shape, Pan Cake Coils, Hydraulic Tubes
End : Plain End, Beveled End, Treaded
Element | C | Cr | Mn | Ni | P | S | Si | Cb/Ta |
---|---|---|---|---|---|---|---|---|
347 | 0.08 max | min: 17.0 max: 20.0 | 2.0 max | min: 9.0 max: 13.0 | 0.04 max | 0.30 max | 0.75 max | min:10x C max: 1.0 |
347H | min: 0.04 max: 0.10 | min: 17.0 max: 20.0 | 2.0 max | min: 9.0 max: 13.0 | 0.03 max | 0.30 max | 0.75 max | min:10x C max: 1.0 |
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
8.0 g/cm3 | 1454 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Stainless Steel 347 and 347H Welded Tubing from Rithav Pipes and Tubes for exceptional corrosion resistance, superior strength and excellent durability. Ideal for a variety of industrial applications it provides outstanding performance in harsh environments. With precision manufacturing and quality assurance, we ensure reliable and durable tubing solutions.
Rithav Pipes and Tubes is the largest supplier of Stainless Steel 317 and 317L Welded Tubing in Delhi, India. Known for its high-quality products. We offer superior corrosion resistance, strength, and durability. Trusted by industries worldwide they provide reliable precision-engineered tubing for various applications and project needs.
STANDARD | WERKSTOFF NR. | UNS | JIS | GOST | EN |
SS 347 | 1.4550 | S34700 | SUS 347 | 08Ch18N12B | X6CrNiNb18-10 |
SS 347H | 1.4961 | S34709 | SUS 347H | – | X6CrNiNb18-12 |
Yes, Rithav Pipes and Tubes offer large custom designs for Stainless Steel 347 and 347H Welded Tubing. With design, wall thickness and length. Their adjustable options ensure the tubing meets specific application requirements. This flexibility makes it more efficient and reliable for different industries and environments. For more details, contact us at sales@rithavpipesandtubes.co.in.
Stainless Steel 347/347H Welded Tubing finds extensive application in applications that require high-temperature strength and corrosion resistance. It is perfect for heat exchangers, pressure vessels, and boilers where stability and strength at high temperatures are necessary. The tubing is also used widely in chemical processing industries, aerospace, and power generation sectors, where it works with hot gases, corrosive liquids, and high-pressure systems without any problems. Its intergranular corrosion resistance makes it especially well-suited for thermal cycling or aggressive chemical exposure environments, with long-term performance, structural integrity, and safety in harsh industrial service.
