Home > Super Duplex Steel > Super Duplex Steel Seamless Tubing
Rithav Pipes and Tubes is a well-respected manufacturer and supplier of Super Duplex Steel Seamless Tubing, proudly based in Delhi, India. We specialize in providing high-quality seamless tubing designed for tough industrial applications that demand exceptional strength and corrosion resistance. Our Super Duplex seamless tubes are crafted with precision to guarantee uniformity, outstanding mechanical properties, and a long service life. Serving industries like oil and gas, petrochemical, marine, and power generation, Rithav Pipes and Tubes is dedicated to delivering products that adhere to international standards, ensuring timely delivery and top-notch customer support, which makes us a go-to choice in both India and global markets.
Super Duplex Steel Seamless Tubing consists of about 25% chromium, 7% nickel, 4% molybdenum, and nitrogen, all of which boost its corrosion resistance and mechanical strength. This dual-phase alloy showcases a well-balanced microstructure of ferrite and austenite, offering impressive tensile strength around 750 MPa and yield strength close to 550 MPa. The seamless manufacturing process guarantees superior structural integrity by eliminating weld seams, enhancing pressure resistance and durability. These tubes are particularly effective at resisting pitting, crevice corrosion, and stress corrosion cracking, making them perfect for harsh, corrosive environments.
| Specifications | ASTM A 789 ASME SA 789 |
|---|---|
| Standard | AISI, DIN, EN, GB, JIS, ASTM, ASME Super Duplex 2507 Pipe |
| 2507 Seamless Pipe Outer Diameter | 6.00 mm OD up to 250 mm OD, Sizes up to 12” NB |
| Alloy 2507 Welded Pipe size | 5.0 mm – 1219.2 mm |
| 2507 EFW Pipe size | 5.0 mm – 1219.2 mm |
| Thickness | 0.3mm – 50 mm |
| SS 2507 Seamless Tube Size | 3.35 mm OD To 101.6 mm OD, 15 NB to 150 NB IN |
| 2507 Welded Tube Size | 6.35 mm OD To 152 mm OD |
| Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| DSS 2507 tubing wall thickness | 0.020″ –0.220″ (special wall thicknesses available) |
| 2507 Pipe Schedule | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Duplex 2507 Pipe & Tube Finish | Polished, AP (Annealed & Pickled), MF, NO.1, NO.4, BA (Bright & Annealed), 2B, BA, HL, 8K, Mirror finish,etc |
| 2507 Pipe & Tube Form | Round, Hollow, Square,Rectangular, Hydraulic, Coiled, Straight Pipes, “U” Shape, Pan Cake Coils etc. |
| Super Duplex 2507 Pipe & Tube Length | Single Random, Double Random, Standard & Cut length |
| 2507 Pipe & Tube End | Beveled End,Plain End, Treaded. |
| 2507 Pipe & Tube Type | 2507 Seamless / ERW/ Welded / Fabricated / EFW / CDW / DOM / CEW Pipes |
| Marking | All 2507 Pipes are marked as follows: Grade, Standard, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Super Duplex 2507 Tube Application | Oil Tube, Gas Tube, Fluid Tube, Boiler and Heatexchanger |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Specialized in | Large Dia 2507 Pipe 2507 Capillary Tube & Other Odd Size 2507 Super Duplex Heat Exchanger & Condenser Tubes |
| Super Duplex | C | N | P | Si | Mn | Mo | Ni | Cr | S | Other |
| 0.030 | 0.24/0.32 | 0.035 | 0.80 | 1.20 | 3.0/5.0 | 6.00/8.00 | 24.0/26.0 | 0.020 | Cu:0.50 |
| Super Duplex | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Super Duplex Steel Seamless Tubing from Rithav Pipes and Tubes ensures superior quality and durability, offering outstanding corrosion resistance and high strength. Our dedication to delivering exceptional service and reliable products guarantees customer satisfaction across a wide range of industrial applications. With our expertise in Super Duplex steel solutions, you can trust us to provide a top-tier, customized piping solution that meets your specific requirements.
Rithav Pipes and Tubes, one of the largest suppliers of Super Duplex Steel Seamless Tubing in the Delhis, India, offers a wide range of high-quality pipes and tubes designed for various industrial applications. Their extensive inventory and dedication to exceptional service make them a trusted choice for Super Duplex steel products in the region, delivering reliable solutions to meet diverse project requirements.
Yes, we provide custom sizes for Super Duplex Steel Seamless Tubes to meet your specific requirements. At Rithav Pipes and Tubes, our team is dedicated to delivering tailored solutions for all your piping and tubing needs. For more information, please contact us at sales@rithavpipesandtubes.co.in.
Super Duplex Steel Seamless Tubing finds extensive use in industries that require strong, corrosion-resistant tubing solutions. In the oil and gas sector, it’s employed for subsea systems, hydraulic lines, and critical process piping. The chemical and petrochemical industries rely on it for managing aggressive chemicals and high-temperature fluids. Marine applications take advantage of its resistance to seawater corrosion, while power generation plants utilize it in heat exchangers and cooling systems. Moreover, desalination plants and the pulp and paper industry trust these tubes for their reliability and long-term performance, even under extreme conditions.
