Rithav Pipes and Tubes is a prominent manufacturer and supplier of Titanium Grade 5 Pipes, with its headquarter in Delhi, India. We are expert manufacturers of high-quality titanium piping solutions for applications that require high strength, corrosion resistance, and reliability at harsh conditions. The most common titanium alloy, Titanium Grade 5 (Ti-6Al-4V), exhibits superior mechanical properties and durability. At Rithav, we implement sophisticated manufacturing techniques and rigorous quality control to provide precision-engineered Grade 5 pipes to international standards, catering to aerospace, marine, chemical processing, defense, and high-performance engineering applications.
Titanium Grade 5 Pipes consist of about 90% titanium, 6% aluminum, and 4% vanadium. This alloy provides superior mechanical properties with tensile strength of about 895 MPa, yield strength of approximately 828 MPa, and elongation of up to 14%. It offers high strength-to-weight ratio, good corrosion resistance, and superior fatigue strength. Titanium Gr 5 exhibits stability at high temperatures and is suitable for high-stress use. Its durability and weldability qualify it as a first choice for demanding structural and fluid-handling systems in aggressive industrial environments.
Specification : ASTM B861, B338, B388, B862 / ASME SB861, SB338, SB388, SB862
Pipe Range : ½”NB to 24”NB / SCH 10 – SCH XXS
Tubes Range: 1mm OD to 254mm OD / Thickness 0.1 to 20mm.
Type : Seamless / ERW / Welded / Fabricated Pipes
Form : Round, Square, Rectangular, Oval, Hydraulic Etc
Length : Single Random, Double Random & Required Length
End : Plain End, Beveled End, Treaded
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Inspection, Test Reports : Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab Reports, Destructive Test Report, Non Destructive Test Reports
Packing : Packed in Wooden Boxes, Plastic Bags, Steel Strips Bundled, or as per Customers Requests
Specials : Sizes and Specifications other than above can be manufactured on request
| Al | Fe | O | Ti | V |
|---|---|---|---|---|
| max | max | max | max | max |
| 6 | 0.25 | 0.2 | 90 | 4 |
| Hardness, Brinell | 334 | 334 | Estimated from Rockwell C. |
|---|---|---|---|
| Hardness, Knoop | 363 | 363 | Estimated from Rockwell C. |
| Hardness, Rockwell C | 36 | 36 | |
| Hardness, Vickers | 349 | 349 | Estimated from Rockwell C. |
| Tensile Strength, Ultimate | 950 MPa | 138000 psi | |
| Tensile Strength, Yield | 880 MPa | 128000 psi | |
| Elongation at Break | 14 % | 14 % | |
| Reduction of Area | 36 % | 36 % | |
| Modulus of Elasticity | 113.8 GPa | 16500 ksi | |
| Compressive Yield Strength | 970 MPa | 141000 psi | |
| Notched Tensile Strength | 1450 MPa | 210000 psi | Kt (stress concentration factor) = 6.7 |
| Ultimate Bearing Strength | 1860 MPa | 270000 psi | e/D = 2 |
| Bearing Yield Strength | 1480 MPa | 215000 psi | e/D = 2 |
| Poisson’s Ratio | 0.342 | 0.342 | |
| Charpy Impact | 17 J | 12.5 ft-lb | V-notch |
| Fatigue Strength | 240 MPa | 34800 psi | at 1E+7 cycles. Kt (stress concentration factor) = 3.3 |
| Fatigue Strength | 510 MPa | 74000 psi | Unnotched 10,000,000 Cycles |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
By choosing Titanium Gr 5 Tubing from Rithav Pipes and Tubes, you are assured of superior quality and durability. These tubes provide outstanding corrosion resistance and strength, making them ideal for a wide range of industrial applications. Our dedication to excellent service and dependable delivery ensures customer satisfaction every time. With our expertise in stainless steel products, we deliver top-tier solutions customized to meet your specific requirements.
Rithav Pipes and Tubes, a leading supplier of Titanium Gr 5 Tubing in Delhi, India, provides a wide selection of premium pipes and tubes for diverse industrial applications. With a vast inventory and a strong focus on delivering outstanding service, they are the preferred choice for stainless steel products in the region.
At Rithav Pipes and Tubes, we provide custom sizes of Titanium Gr 5 Tubing to meet your exact specifications. Our dedicated team is here to offer tailored solutions for all your piping and tubing needs. For more information, feel free to reach out to us at sales@brydonpipesandtubes.co.uk.
Titanium Grade 5 Pipes find application across a wide range of demanding applications in industries. They play a critical role in the aerospace industry in airframes, engine parts, and hydraulic systems because of their light weight and resistance to heat. In the marine sector, they are employed in seawater piping, ship equipment, and offshore pipelines for their resistance to corrosion. Chemical and petrochemical facilities use them for handling pressure-carrying corrosive fluids. Grade 5 pipes are used in medical uses for implants and for surgical implements. They also appear in automotive, defense, and power generation industries that need high-performance, durable materials.
